The Christie® DHD800 offers full HD and high-brightness in a 1-chip DLP® projector, making it ideally suited for a variety of applications including fixed installs and live events. At 8000 ANSI lumens, it’s one of the brightest 1-chip DLP dual-lamp projectors on the market. With full HD resolution, this projector is compatible with most computers and video sources.

A unique, user-changeable, twin-color-wheel system gives you the flexibility to tailor your presentations to maximize high-brightness images and achieve superior-color reproduction. Ideal for 24/7 operation, the Christie DHD800 includes a lamp-interval feature that enables you to select the usage times between the dual-lamps for balanced lamp life.Its sealed optical engine prevents dust and dirt from affecting the system, ensuring that image quality is maintained and maintenance costs are lower.

Featuring the latest in DLP technology including Brilliant Color™, along with Philips’ VIDI™ lamps, the Christie DHD800 is a professional grade projector ready for 24/7 or extended* use applications.


  • Full HD (1920 x 1080) native resolution
  • 8,000 ANSI lumens, dual-lamp platform
  • Sealed 1-chip DLP light engine
  • Optional extended-use AutoFilter
  • 7500:1 with rich black reproduction contrast ratio
  • User-changeable color wheels - RGBW or RGBCYM for high-brightness or superior rich-color use
  • Built-in edge-blending and color-matching capabilities
  • Flexible and customizable – install it anywhere, connect to virtually anything
  • Auto-switching lamp
  • 24/7 operation1

1 Christie 1-chip DLP projectors can be used in 24/7 or extended use applications. Regular maintenance and a 24/7 maintenance kit are recommended to maximize the lifetime of your projector.

Built-in color-matching and edge-blending functions, picture-in-picture or picture-by-picture modes and low acoustic noise offer presentation confidence and installation flexibility. With its HD lens options and connection expandability, this 1-chip DLP solution is easy to use and maintain - install it anywhere and connect to virtually anything.

Exceptional image quality, 24/7 performance reliability and application flexibility make the Christie DHD800 digital projector an excellent choice for large video presentations with high resolution content.

Brighter. Bolder. Better!



  • - 8000 ANSI lumens - high brightness color wheel
  • - 5000 lumens - rich color reproduction wheel
  • - contrast ratio: up to 7500:1 with rich black reproduction

Display technology

  • 1-chip 0.95" DLP light engine
  • HD 1920 x 1080


  • - Dual 330W VIDI™ UHP
  • Standard mode: up to 2000hrs
  • Eco mode: up to 3000 hours

Input signal compatibility

  • Video(480i,480P,720P,1080i, 1080p/psf)

Pixel clock

  • Analog 230 MHz / Digital 160 MHz max

Scan rates

  • Horizontal: 15-100kHz; Vertical: 48-100Hz

Due to constant research, specifications and features are subject to change without notice.
