When you’re looking to stand out from the crowd with bright, impressive visuals and you don’t want to blow your budget, the 22,500-lumen, high-performance Christie® 4K22-HS is the perfect fit.

Your audience will enjoy incredible brightness and resolution, plus enhanced color performance from the brightest 4K UHD 1DLP® projector on the market. The 4K22-HS delivers deeper blacks and more natural and realistic onscreen visuals thanks to Christie BoldColor+ technology.

Using onboard Christie Twistwarping and blending, you can quickly and easily set up and align irregular screens and multi-projector displays. The option to add Christie Mystique automated camera-based alignment software lets you quickly stage, install, align, and recalibrate multi-projection systems in minutes.

And as if that wasn’t enough, the 4K22-HS comes with a 5-year warranty and supports active and passive polarized 3D right out of the box.

Key features

  • High brightness– The first 4K UHD 1DLP projector on the market with 22,500 ISO lumens/19,000 ANSI lumens
  • Premium color – Christie BoldColor+ gives audiences enhanced color performance—with deeper blacks and more natural and realistic onscreen visuals.
  • Warping and blending – Make setup even easier with proprietary Christie Twist built-in for quick and easy setup of multi-projector displays
  • RealBlack™ technology – Produces the deepest possible black on-screen by completely turning off the laser light when displaying black scenes.
  • Compatible with Christie Mystique automated camera-based alignment and recalibration software that lets you quickly install, align, calibrate, and maintain multi-projection systems
  • Compatible with Christie Intelligent Camera (CIC) – Use CIC to trigger autofocus, automatically calibrate projector color, optimize color uniformity, and more
  • Advanced electronics deliver high frame rates for 4K UHD at 60 Hz and 1080p at 240 Hz
  • HDBaseT solution – Supports HD video streaming through RJ45
  • AMX and Crestron connectivity - For enhanced collaboration and easy integration into virtually any existing boardroom
  • Support for active and passive polarized 3D provides additional versatility
  • Full suite of lenses – Compatible with WUXGA HS Series lenses* including 0.65:1 to 10.8:1 and a 0.38:1 UST lens
  • Quiet operation – As low as 42dBA
  • Eco Mode – Reduces brightness to 50%, significantly extending the lifetime of your projector, and results in quieter operation
  • Full-range voltage support (100 to 240 VAC) The system dims to 80% brightness when it detects 100-120 VAC power

*The 4K22-HS is not compatible with the WUXGA 0.84-1.02:1 short zoom lens.

* 35dBA in Eco2 mode (2x wheel speed) and 39dBA in standard mode (3x wheel speed).



TAA compliant logo

5 year warranty



We’re here to support your investment

Backed by Christie's industry-leading warranties, service, and support, you can feel confident investing in the Christie HS Series.
If you have any questions or want to speak to a Christie sales representative, please contact us.

Videos

Open a new world of projected color with Christie BoldColor and BoldColor technology

Open a new world of projected color with Christie BoldColor technology

Specifications

22,500

ISO lumens

19,000

ANSI lumens

3 Segment (RGB) - 4X speed

Color wheel

4,000,000:1 with Christie RealBlack™ *

Contrast ratio

6,000:1

Dynamic contrast

1 x 0.95" DMD

Display type

Notes:

* 1,200:1 with Christie RealBlack disabled

** Reference the Christie Standard Limited Warranty document for details.
