Christie 4K22-HS | Christie - Audio Visual Solutions
Overview Specs Accessories Downloads Images

When you’re looking to stand out from the crowd with bright, impressive visuals and you don’t want to blow your budget, the 22,500-lumen, high-performance Christie® 4K22-HS is the perfect fit.

Your audience will enjoy incredible brightness and resolution, plus enhanced color performance from the brightest 4K UHD 1DLP® projector on the market. The 4K22-HS delivers deeper blacks and more natural and realistic onscreen visuals thanks to Christie BoldColor+ technology.

Using onboard Christie Twistwarping and blending, you can quickly and easily set up and align irregular screens and multi-projector displays. The option to add Christie Mystique automated camera-based alignment software lets you quickly stage, install, align, and recalibrate multi-projection systems in minutes.

And as if that wasn’t enough, the 4K22-HS comes with a 5-year warranty and supports active and passive polarized 3D right out of the box.

Key features

  • High brightness– The first 4K UHD 1DLP projector on the market with 22,500 ISO lumens/19,000 ANSI lumens
  • Premium color – Christie BoldColor+ gives audiences enhanced color performance—with deeper blacks and more natural and realistic onscreen visuals.
  • Warping and blending – Make setup even easier with proprietary Christie Twist built-in for quick and easy setup of multi-projector displays
  • RealBlack™ technology – Produces the deepest possible black on-screen by completely turning off the laser light when displaying black scenes.
  • Compatible with Christie Mystique automated camera-based alignment and recalibration software that lets you quickly install, align, calibrate, and maintain multi-projection systems
  • Compatible with Christie Intelligent Camera (CIC) – Use CIC to trigger autofocus, automatically calibrate projector color, optimize color uniformity, and more
  • Advanced electronics deliver high frame rates for 4K UHD at 60 Hz and 1080p at 240 Hz
  • HDBaseT solution – Supports HD video streaming through RJ45
  • AMX and Crestron connectivity - For enhanced collaboration and easy integration into virtually any existing boardroom
  • Support for active and passive polarized 3D provides additional versatility
  • Full suite of lenses – Compatible with WUXGA HS Series lenses* including 0.65:1 to 10.8:1 and a 0.38:1 UST lens
  • Quiet operation – As low as 42dBA
  • Eco Mode – Reduces brightness to 50%, significantly extending the lifetime of your projector, and results in quieter operation
  • Full-range voltage support (100 to 240 VAC) The system dims to 80% brightness when it detects 100-120 VAC power

*The 4K22-HS is not compatible with the WUXGA 0.84-1.02:1 short zoom lens.

* 35dBA in Eco2 mode (2x wheel speed) and 39dBA in standard mode (3x wheel speed).



TAA compliant logo

5 year warranty



We’re here to support your investment

Backed by Christie's industry-leading warranties, service, and support, you can feel confident investing in the Christie HS Series.
If you have any questions or want to speak to a Christie sales representative, please contact us.

Specifications

22,500

ISO lumens

19,000

ANSI lumens

3 Segment (RGB) - 4X speed

Color wheel

4,000,000:1 with Christie RealBlack™ *

Contrast ratio

6,000:1

Dynamic contrast

1 x 0.95" DMD

Display type

Notes:

* 1,200:1 with Christie RealBlack disabled

** Reference the Christie Standard Limited Warranty document for details.
