ISO lumens

0

Center lumens

0

Resolution

WUXGA (1920 x 1200)

Inputs, Control & Networking

• - RS232 in/out
• - RS422 in
• - Ethernet (10/100)
• - USB device
• - GPIO (RS232 9-pin male connector)
• - Dual 7 segment status display
• - Remote control (with optional wired XLR connection)
• - Slot 1-2 standard (populated): two Dual link DVI-D (330MHz) input cards. Each has a VGA (165MHz) port
• - Slots 3-4 unpopulated
• - Full bandwidth Analog BNC
• - Dual Link DVI input card (330MHz), VGA (165MHz)
• - Dual SD/HD-SDI
• - Video Decoder*
• - Twin HDMI
• - Two standard Dual Link DVI input cards (330MHz)
• - *The Dual link DVI input card has a 330MHz DVI-I connector which can support a single or dual-link DVI, analog and HDCP video signals with proper cables. There is also an additional 15-pin VGA connector for signals under 165MHz. Only one input is active on this card at a time. Two of these cards come standard on the Christie Mirage WU-L

Optical system

• Lens mount:
• - Mechanical, horizontal and vertical lens shift
• - No shutter required
• - No iris required – user programmable illumination parameters (eliminates the need for a mechanical shutter)
• - Christie ArrayLOC™ :
• - Manages the brightness and color levels of all projectors within an array to a common level, in real-time with no additional latency

Lenses* - standard or optional

• Fixed:
• - 0.64:1 WUXGA lens
• - 0.75:1 WUXGA lens
• Zoom:
• - 1.2-1.6:1 WUXGA lens
• Offsets:
• - 0.64:1 lens features ±5% (horizontal) and ±5% (vertical) offset when mounted in landscape orientation
• - 0.75:1 lens features ±80% (horizontal) and ±100% (vertical) offset when mounted in landscape orientation
• - 1.2-1.6:1 lens features ±80% (horizontal) and ±100% (vertical) offset when mounted in landscape orientation
• - *Each offset is specified with the other at zero. Simultaneous horizontal and vertical offsets may limit the adjustment range of each

Standard accessories

• User manual
• IR remote with hard wired cord
• Line cord
• Two Dual Link DVI-D Cards
• 3D sync cable

Enhanced feature sets

• - Minimum Processing Latency (MPL™)
• - Christie Twist™ II – advanced warping/edge-blending hardware technology integrated directly into the projector, includes warping/blending software
• - Auto set up, power up
• - Menus in 8 languages Multiple channel memories (for recall memory storage)
• - Christie ArrayLOC™ – automatic, continuous management of brightness and color space levels of all projectors in an array to a common level, in real-time

Power requirements

• - operating voltage: 100-240 VAC 50/60Hz
• - operating current: 5.3A
• dissipation: 1364 BTU/hr (variable, dependent on content)

Dimensions

• Size:
• - Projector head module + light module (no lens): 8.7 x 18.4 x 11.0" (220 x 467 x 287mm)
• Electronics module: 16.5 x 5.5 x 6.7" (420 x 140 x 170mm)

Weight

• - Projector head module + light module (no lens): 32lb (14.6kg)
• - Electronics module: 9.7lbs (4.4kg)
• - Shipping weight:
• - 52lb (23.6kg)

Operating Environment

• - Noise: 38dBA at 25°C ambient temperature (without electronics module)
• - Operating temperature: 40-95ºF (5-35ºC)
• - Humidity: 20-80% non-condensing

Regulatory Approvals

• - Directives (EC) 2002/95/EC (RoHS)
• - 2002/96/EC (WEEE)
• - Regulation (EC) No. 1907/2006 (REACH)
• - CAN/CSA C22.2 No. 60950-1
• - UL 60950-1
• - IEC 60950-1
• - FCC, Part 15, Subpart B, Class A
• - EN55022/CISPR22 Class A
• - EN55024 / CISPR24
• Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), KC/KCC (Korea), PSE (Japan), C-Tick (Australia & New Zealand)

Warranty

• - 2 years parts and labor (inclusive)
• - Contact an authorized Christie representative for full details of our limited warranty
