Low profile
Versatility in installation
Christie® screen channel loudspeakers combine advanced ribbon driver technology with a unique line array design to provide greatly enhanced clarity, dramatically reduced distortion and ultra-fast transient response. Featuring very wide horizontal dispersion and highly controlled vertical dispersion patterns, Christie’s screen channel loudspeakers place sound exactly where it is needed, increasing the optimal listening area up to four times greater than conventional cinema audio systems.
Features:
- Christie single enclosure coaxial arcuate line array design
- Ribbon driver technology representing the next evolution of loudspeaker design
- Provides approximately four times the optimal listening area than typical cinema audio systems
- Enhanced voice intelligibility, low distortion and highly controlled dispersion
No listening fatigue
Extended listening comfort throughout the movie
Ribbon driver
10x less distortion than competing drivers with better auditorium coverage
Speech clarity
Hear every detail of the dialogue
Specifications
System type
- Four-way, bi-amp, ported enclosure
Driver components
- HF: 2 x 3" high output ribbon drivers with Kapton® diaphragm and Neodymium magnets
- MF: 6.5" paper/Kevlar high efficiency midrange cone driver with 38mm voice coil
- LF: 15" paper composite cone driver with 100mm diameter voice coil
Crossover
- LF-MF: 350Hz, active via processor
- MF-HF: passive @ 2.0kHz
- Two-way HF section with frequency shading network
Frequency response*
- 30Hz-20kHz @ -6dB
Maximum SPL**
- LF: 123dB continuous, 135dB peak
- MF-HF: 123dB continuous, 135dB peak
- LS1 system: 126dB continuous, 138dB peak
System coverage***
- 100° horizontal dispersion
- 40° vertical dispersion
*Measured at 2m on tweeter axis in simulated free field conditions. Near field measurements were used for low-frequency data. Sensitivity is calculated based on measured SPL response averaged in 200Hz-5kHz range.
**IEC refers to IEC 60268-5 standard. Max SPL calculated based on sensitivity and power handling. IEC short-term power tested using IEC pink noise with 9dB crest factor. The crest factor was specifically increased to reflect real-life parameters of digital cinema sound tracks. Maximum peak SPL calculated using peak voltage during IEC short-term power test. Continuous power handling tested using IEC60268-1 noise signal for duration of 2 hours.
***Averaged in 500Hz-12kHz range, at -6dB
Downloads
Christie Cinema Solutions Brochure
Jan 01, 2017 | PDF: 1.1 MB
This document is a PDF version of the Christie Cinema Solutions brochure. It contains high-level information on what Christie offers the cinema production, post production and exhibition communities including our industry leading digital cinema projectors, our integrated media block, our theatre management solutions and our service and support. Please refer to the information presented on the Christie website or speak to your Christie representative for the confirmation of installation-critical specifications and features.
Christie Vive Audio LS1 Specsheet
Apr 05, 2016 | PDF: 2.8 MB
This document outlines the detailed specifications for the Christie Vive Audio LS1 line source loudspeakers.
