ISO lumens

6,750

Center lumens

6,000

ANSI lumens

6,000

Color wheel

4 Segment (RGBY) - 2X or 3X speed

Contrast ratio

Full on/off (Christie RealBlack™ enabled): 300,000:1, Full on/off (Christie Real Black disabled): 1,200:1

Dynamic contrast

6,000:1

Display type

1 x 0.67" DMD

Resolution

WUXGA (1920 x 1200)

Illumination type

High efficiency blue laser phosphor

Illumination performance (hrs)

20,000 to 50% brightness

Scan rates

Horizontal: 15-91kHz, Vertical: 24- 120Hz

Pixel clock rate

162 MHz (1600 x 1200); 154 MHz (1920 x 1200)

Signal input

• Standard:
• - HDMI x 2
• - DVI-D x 1 (Digital only)
• - HD15 x 1
• - Remote in: 3.5mm stereo female (provides serial communications and power)
• - HDBaseT (RJ45 x 1)
• - RJ45 x 1 (Control over wired network connection)
• 3D:
• - HDMI 1.4, HDBaseT - Frame Packed, Top/Bottom, Side by side (Up to 1080p @ 144Hz)
• - Up to 1080p @ 144Hz output
• - Does not support frame sequential 3D
• - 3D Sync Out (BNC) - for genlocking projectors or controlling emitters
• Signals:
• - HDTV formats VGA through to WUXGA (1920 x 1080)
• - Horizontal and vertical scaling while maintaining aspect ratio, all inputs

Signal output

• HD15 x1

Control & networking

• - RS232 In
• - Control via HDBaseT
• - Ethernet (10/100) RJ45
• - Built-in backlit keypad
• - IR remote
• - Wired remote control (3.5mm stereo)

Lens mount

• - Boresight adjustable
• - Motorized horizontal and vertical lens offset
• - Motorized zoom and focus adjustment

Lens options

• - Lens 0.75-0.95 Zoom G/GS
• - Lens 0.95-1.22 Zoom G/GS
• - Lens Zoom HP G/GS 1.22-1.52
• - Lens 1.52-2.89 Zoom G/GS
• - Lens 2.9-5.50:1 Zoom G/GS
• - Lens UST 0.36 (140-133108-XX)

Power requirements

• Operating voltage:
• - Normal: 100-240 VAC @ 50/60 Hz (w/ 15A fuse)
• Power consumption:
• - Normal mode: 650W
• Operating current:
• - Normal mode: 9.5A (100V-240V)
• Dissipation:
• 97.5W

Dissipation

• Normal Mode: 2218 BTU/hr
• ECO1 Mode 1672 BTU/hr
• ECO2 Mode: 1068 BTU/h

Audible noise (typical 2x wheel speed)

• 36dB(A) standard mode
• - 34dB(A) eco mode

Dimensions (L x W x H)

• - 19.90 x 17.95 x 7.60" without feet or lens
• - 505 x 456 x 190mm without feet or lens

Weight

• 39.94lbs (15.85kg) without lens

Shipping dimensions (L x W x H)

• - 24.65 x 23.43 x 13.74"
• - 626 x 596 x 349mm

Shipping weight

• 47.06lb (21.35kg)

Operating environment

• - 0 to 40° C (32 to 1- 04° F), 0-2500 ft altitude
• - 0 to 30° C (32 to 86° F), 5,000-10,000 ft altitude
• - Humidity: 0 - 85% non-condensing

Regulatory

• - Contact Christie for timing of certifications: UL/CSA/IEC 60950-1
• - FCC Class A, CE, FDA, CCC, KC, PSE, EAC, BIS, VCCI, RCM, TER
• - This product conforms to all relevant European directives, standards, safety, health and environmental concerns
• - RoHS, REACH, WEEE

Limited warranty

• - 3 years parts and labor on the projector
• - 3 years or 20,000 hours parts and labor on the illumination system*
• - Contact an authorized Christie representative for full details of our limited warranty
• - *Please reference the Christie Standard Limited Warranty document for details.

Accessories (standard)

• - IR Remote w/ wired remote jack (wire not included)
• - AC Line cords for projector
• - User Manual
